Description
The Carrier 69RG15-120W-24 Clip-On Generator Set is engineered to provide continuous, dependable power for refrigerated ISO shipping containers during road or rail transport. Designed to mount directly to the top corner castings above container refrigeration units, this generator enables reliable unattended operation in transit to maintain cargo temperature integrity.
Powered by a 2.4-liter V2403-CR-E4B 4-cylinder water-cooled diesel engine with common rail injection, the unit delivers a nominal 15 kW output (460V, 3-phase). It features an integrated 120-gallon fuel tank and a high-efficiency permanent magnet generator managed by an advanced controller with FuelWise functionality for optimal fuel management.
Constructed for demanding industrial environments, the assembly includes a powder-coated frame and sheet metal housing, stainless steel hardware and exhaust, an E-coat tube and fin radiator, and enclosed forklift pockets for secure handling. Low-mounted controls and a large aluminum service access door facilitate straightforward operation and maintenance.
| Brand | Carrier Transicold |
| Model Number | 69RG15-120W-24 |
| Engine | V2403-CR-E4B, 4-cylinder, water-cooled, 2.4-liter, common rail injection diesel engine |
| Power Output | 15 kW |
| Electrical Specifications | 3-phase, 460V |
| Fuel Tank Capacity | 120 gal |
| Weight | 1974 lb (less fuel) |
| Mounting Type | Pin-mount clip-on system |
| Air Cleaner | High-efficiency dry element air cleaner |
| Oil Filter | Full-flow spin-on oil filter with internal bypass |
| Radiator | E-coat tube and fin radiator |
| Battery | 12V DC maintenance-free |
| Structure Ambient Temperature Range | -40° to +125° F (-40° to +52° C) |
| Operation Start Ambient Temperature Range | -15° to +125° F (-26° to +52° C) |
| Operation Run Ambient Temperature Range | -40° to +125° F (-40° to +52° C) |
