Description
The Carrier Transicold PowerLINE 69UG15-068S-05 undermount generator set is engineered for continuous, unattended operation under chassis during road and rail transport. Designed specifically to power ISO refrigerated containers in transit or at remote locations where grid power is unavailable, it delivers dependable performance, torque, and motor-starting capability.
Powered by a robust CT4-134Di 4-cylinder, 2.2-liter water-cooled direct-injection diesel engine, this generator delivers a nominal 15 kW brushless, self-regulated output. It features an all-steel fabricated frame with 4-point plate-mount hangers for secure under-chassis installation, enclosed forklift pockets for easy handling, and a large service access door with a quick-release latch.
Key operational features include a 50-gallon (189 L) integral fuel tank, an epoxy-dipped tube-and-fin radiator, an electric fuel warmer integrated into the filter, and a high-capacity oil pan designed for up to 2,000 running hours between service intervals. Safety is prioritized with automatic stop controls for low oil pressure and high water temperature, a waterproof control box with driver-side access, and a 460V power output receptacle with a protective spring-loaded cap.
| Brand | Carrier |
| Manufacturer | Carrier Transicold |
| Model Number | 69UG15-068S-05 |
| Product Type | Undermount Generator Set |
| Rated Output Power | 15 kW |
| Fuel Type | Diesel |
| Engine | CT4-134Di 4-cylinder water-cooled, 2.2L direct-injection |
| Fuel Tank Capacity | 50 gal (189 L) |
| Output Voltage | 460V |
| Generator Type | Brushless, self-regulated |
| Battery | 12V DC maintenance-free |
| Weight (Less Fuel) | 1,370 lb (621 kg) |
| Mounting System | All-steel frame with 4-point plate-mount hangers |
| Safety Features | Low oil pressure and high water temperature stop controls |
