Description
The Carrier Transicold PowerLINE 69UG15-068S-05 undermount generator set provides reliable, continuous, unattended power for refrigerated ISO containers transported by road or rail. Engineered for demanding transport environments, this under-chassis diesel generator delivers the necessary horsepower, torque, and motor-starting capability to maintain continuous cold chain refrigeration in transit or in remote locations without available grid power.
Engine and Power Generation
Equipped with a V2203-DI 4-cylinder, water-cooled, 2.2 L direct-injection diesel engine generating 32 HP (23.9 kW), the unit meets EPA Tier 4 interim standards for export. It drives a nominal 15 kW brushless, self-regulated generator outputting 460V through a protected receptacle with a spring-loaded cap.
Durable Construction and Cooling
Built with an all-steel fabricated frame and powder-coated sheet metal components, the genset offers superior corrosion protection. Thermal management includes a patented E-coat tube and fin radiator, alongside a self-tensioning Poly V belt that optimizes water pump bearing life and eliminates manual adjustments.
Fuel and Service Efficiency
Designed for extended maintenance intervals, the system features a large-capacity oil pan rated for 2,000 running hours between oil changes, a full-flow spin-on oil filter with internal bypass filtration, and an integral fuel filter with a water separator and fuel heater. An external in-line fuel strainer with a clear bowl enables quick visual inspections. Access is streamlined via a large aluminum service door with quick-release latches, driver-side controls, and integrated forklift pockets for flexible mounting.
| Brand | Carrier |
| Manufacturer | Carrier Transicold |
| Model Number | 69UG15-068S-05 |
| Product Type | Undermount Generator Set |
| Engine Model | V2203-DI |
| Engine Type | 4-cylinder, water-cooled, 2.2-liter direct-injection diesel |
| Horsepower | 32 HP / 23.9 kW |
| Generator Output | Nominal 15 kW, 460V |
| Generator Type | Brushless, self-regulated |
| Fuel Type | Diesel |
| Fuel Tank Options | 50, 68, 80 gallon |
| Battery | 12V DC maintenance-free |
| Mounting System | Standard 4-point mounting or quick clamps system |
| Emission Standard | EPA Tier 4 interim (export outside the US) |
| Ambient Temperature Range (Structure) | -40 to +52°C (-40 to +125°F) |
| Ambient Temperature Range (Operation – Start) | -26 to +52°C (-15 to +125°F) |
| Ambient Temperature Range (Operation – Run) | -40 to +52°C (-40 to +125°F) |
