Description
The Manchester Tank PA-515-B 1000 Gallon Horizontal Above Ground Propane Tank is engineered for heavy-duty residential, commercial, and agricultural energy storage. Designed to provide a dependable energy supply for whole-home heating, large commercial appliances, fleet refueling, and backup generators, this vessel delivers safe and efficient propane containment.
Constructed from high-grade carbon steel, this pressure vessel conforms to ASME Section VIII, Division 1 standards and complies with NFPA 58 regulations. The exterior is finished with ArcClad zinc-rich epoxy primer and a durable TGIC polyester topcoat for superior resistance against weathering and corrosion in outdoor environments. Rated at 250 psig from -20°F to 125°F, this tank offers reliable performance and simplified above-ground installation.
| Brand | Manchester Tank |
| Model Number | PA-515-B |
| Product Type | Above Ground Propane Tank |
| Material | Carbon Steel |
| Water Capacity | 1000 gal (3,785.0 L) |
| Propane Capacity | Approx. 800 gal |
| Pressure Rating | 250 psig |
| Standards & Compliance | ASME Section VIII Div 1, NFPA 58 |
| Outside Diameter | 40.96 in (1,040.4 mm) |
| Overall Length | 15 ft 10-13/16 in (4,846.6 mm) |
| Overall Height | 4 ft 1-3/8 in (1,254.1 mm) |
| Leg Spacing | 9 ft 0 in (2,743.2 mm) |
| Leg Width | 16-1/4 in (412.8 mm) |
| Gross Weight | 1729 lb (784.3 kg) |
| Head Type | Hemi |
| Finish | ArcClad Zinc-Rich Epoxy Primer with TGIC Powder Coat |
